Problems with setting up my minecraft server via external IP

Problems with setting up my minecraft server via external IP - Person in Black Long Sleeve Shirt and White Pants

I tried various of things already, I wanted to make my server using my internet, but I couldn't get my friend to join it. I gave him my external IP and with or without putting port at the end worked. In theory the ports are forwarded, I tried multiple combinations and nothing worked.

This is my server.properties config:

#Minecraft server properties
#Fri Jul 16 16:02:05 CEST 2021
spawn-protection=10
max-tick-time=60000
query.port=25565
generator-settings=
sync-chunk-writes=true
force-gamemode=false
allow-nether=true
enforce-whitelist=false
gamemode=survival
broadcast-console-to-ops=true
enable-query=false
player-idle-timeout=0
text-filtering-config=
difficulty=normal
spawn-monsters=true
broadcast-rcon-to-ops=true
op-permission-level=4
pvp=true
entity-broadcast-range-percentage=100
snooper-enabled=true
level-type=default
hardcore=false
enable-status=true
enable-command-block=true
max-players=10
network-compression-threshold=256
resource-pack-sha1=
max-world-size=29999984
function-permission-level=2
rcon.port=25575
server-port=25565
server-ip=
spawn-npcs=true
allow-flight=false
level-name=world
view-distance=10
resource-pack=
spawn-animals=true
white-list=false
rcon.password=
generate-structures=true
max-build-height=256
online-mode=false
level-seed=
use-native-transport=true
prevent-proxy-connections=false
enable-jmx-monitoring=false
enable-rcon=false
rate-limit=0
motd=I'm just a meeeeemmmeeeeer and I meemmmeeee my life.....awaayyyy....awaaay

If there is something more you'll need from me, ask in the comment, but i will be skeptical about showing my IP, because I don't want DoS threats out of curiosity.



Best Answer

There are multiple thing to know and to check according your internet config. I give you a short checklist:

  • Check on your local PC, that you server is running on the port you expect (Simpli try to connect on the same PC with "localhost" as target)
  • Check if you have running any Firewalls on your local PC, that could block your port
    • you can try to connect from another PC in your local network to at least test if the port is open localy)
  • Add port-forwarding in your router to your local pc
  • Make your the IP you give to your friend is the real Internet-IP (you could use https://www.wieistmeineip.de/)
    • I recommend using IPv4, because IPv6 is very complicated to use for custom servers)

If thats all done, check if yout Port is reachable from "outside" you can use

https://api.mcsrvstat.us/1/YOUR-SERVER:YOUR-PORT

e.g. if your public ip is 1.2.3.4 open

https://api.mcsrvstat.us/1/1.2.3.4:25565

The response should something like this

{
  "online": true,
  "ip": "1.2.3.4",
  "port": 25565,
   // and more stuff
}

When your server is online (Important for you is online: true)




Pictures about "Problems with setting up my minecraft server via external IP"

Problems with setting up my minecraft server via external IP - Person Holding Pastry Dishes on White Ceramic Plates
Problems with setting up my minecraft server via external IP - Table Setting for One PersonĀ
Problems with setting up my minecraft server via external IP - Electrician Fixing an Opened Switchboard



Quick Answer about "Problems with setting up my minecraft server via external IP"

  • Check on your local PC, that you server is running on the port you expect (Simpli try to connect on the same PC with "localhost" as target)
  • Check if you have running any Firewalls on your local PC, that could block your port. ...
  • Add port-forwarding in your router to your local pc.


Can you connect to your own Minecraft server with external IP?

You generally cannot connect to the external IP address when coming from inside your network since you reach the router "from the wrong side". The port forwarding only works (generally) when you're coming from the outside.

How do I connect to a Minecraft server with an IP address?

To access a server using the IP address, follow these instructions:
  • Open Minecraft on your computer.
  • Click on the option for 'Direct Connect'
  • Paste or type in the Server IP address (this may also be a domain name as well)
  • Click 'Join Server'




  • Minecraft - Why can only I join my own server? [FIX / SOLVED] (WINDOWS 10)




    More answers regarding problems with setting up my minecraft server via external IP

    Answer 2

    Try disabling firewall and see if your friend can join. Minecraft is safe to run when there's no firewall, in case you're wondering. If that doesn't work he can disable firewall and try to join.
